| Diaphragm Pumps for Air |
| Model |
FREE FLOW |
VOLTAGE |
MAX.PRESSURE |
MAX.VACUUM |
WEIGHT |
DIMENSION |
| DA10DCB |
0.6L/M |
6V |
0.5BAR |
-50KPA |
23G |
49*22*13.2MM |
| DA10DCB-TH |
1L/M |
6V |
0.5BAR |
-50KPA |
32G |
52.45*28.7*33.2MM |
| DA10DCB-THS |
0.6L/M |
6v |
1.4bar |
-80kpa |
32g |
52.45*28.7*33.2mm |
| DA10DCG |
0.6L/M |
3V 6V |
0.5BAR |
-50KPA |
0.02KG |
31*22*13.2MM |
| DA10DCG-TH |
1L/M |
3V 6V |
0.5BAR |
-50KPA |
0.02KG |
44.45*33.2*14MM |
| DA10DCG-THS |
0.6L/M |
3V 6V |
1.4BAR |
-80KPA |
30G |
44.45*33.2*14MM |
| DA10EEDC |
0.4L/M |
3V 6V |
0.4BAR |
-40KPA |
11G |
31*13*22MM |
| DA120DC |
32L/M |
12V 24V |
1.5BAR |
-75KPA |
0.9KG |
137.7*60*95.3MM |
| DA120DC-TH |
64L/M |
12V 24V |
1.5BAR |
-75KPA |
1.2KG |
147.8*99.6*130.5MM |
| DA120DCB |
32L/M |
DC12V DC24V |
1.8Bar |
-80kpa |
0.9kg |
126.6*70*95.3mm |
| DA120DCB-TH |
64L/M |
DC12V 24V |
1.8Bar |
-80kpa |
1.2kg |
189*70*130mm |
| DA20EEDC |
600ml/M |
DC3V 5V 6V |
0.3Bar |
-40kpa |
18G |
31*17*25mm |
| DA20EEDCB |
600ml/m |
6V / 12V |
0.3Bar |
-40kpa |
25G |
48*25*17MM |
| DA20EEGDC |
600ml/m |
6V 12V |
0.3Bar |
-40kpa |
20G |
41*25*17MM |
| DA30EEDC |
1.5L/M |
3v 5V 12V |
0.7BAR |
-45KPA |
35G |
40*23*36mm |
| DA30EEDCB |
1.5L/M |
6V 12V |
0.7BAR |
-45KPA |
48G |
48*23*36MM |
| DA30EEGDC |
1.5L/M |
6V 12V |
0.7BAR |
-45KPA |
38G |
40*23*36MM |
| DA31EEDC |
1.2L/min 1.52l/m |
5V/12V |
0.5Bar |
-40kpa |
35g |
41*22*29mm |
| DA31EEDCB |
1.2L/M |
5V 12V |
0.5BAR |
-40KPA |
35G |
41*22*29MM |
| DA31EEGDC |
1.2L/min |
6V / 12V |
0.5Bar |
-40kpa |
40g |
41*22*29mm |
| DA32EEDC |
1.7L/M |
5V 12V |
0.45BAR |
-45KPA |
34G |
44*35*22MM |
| DA32EEDCB |
1.7L/M |
6V 12V |
0.45BAR |
-45KPA |
51G |
55*35*22MM |
| DA32EEGDC |
1.7L/M |
6V 12V |
0.45BAR |
-45KPA |
40G |
45*35*22MM |
| DA34EEDC |
2.2L/M |
5V 12V |
0.65Bar |
-55KPA |
34G |
44*35*22MM |
| DA34EEDCB |
2.2L/M |
6V 12V |
0.65Bar |
-55KPA |
51G |
55*35*22MM |
| DA34EEGDC |
2.2L/M |
6V 12V |
0.65Bar |
-55KPA |
40G |
45*35*22MM |
| DA36EEDC |
2.5L/M |
6V 12V 24V |
0.9Bar |
-65KPA |
55g |
51*40*22mm |
| DA36EEDCB |
2.5L/M |
6V 12V 24V |
0.9Bar |
-65KPA |
46G |
38*40*23MM |
| DA36EEGDC |
2.5L/M |
6V 12V 24V |
0.9Bar |
-65KPA |
80G |
53*40*23MM |
| DA40EEAC |
3.0l/m |
220V 110V |
1.3BAR |
-70KPA |
1.25KG |
124*89*61MM |
| DA40EEDC |
3.0l/m |
6V 12V 24V |
1.3BAR |
-70KPA |
180G |
80*50*30MM |
| DA40EEDC-TH |
6.0L/M 3.0L/M |
12V 24V |
1.3BAR 2BAR |
-70KPA -90KPA |
340G |
125*55*26MM |
| DA40EEDCB |
3.0l/m |
12V 24V |
1.3BAR |
-70KPA |
200G |
93*50*30MM |
| DA40RHAC |
2.5L/M |
220V |
1.2BAR |
-60KPA |
0.68KG |
*** |
| DA40RHDC |
2.5L/M |
12V 24V |
1.2BAR |
-60KPA |
0.19KG |
83*31*51MM |
| DA40RHDCB |
2.5L/M |
12V 24V |
1.2BAR |
-60KPA |
0.19KG |
*** |
| DA45EEAC |
2.5L/M |
220V/110V |
0.85Bar |
-70Kpa |
1.25kg |
124*89*61mm |
| DA45EEDC |
4.5L/M |
6V 12V 24V |
1.3BAR |
-70KPA |
190G |
80*50*30MM |
| DA45EEDC-TH |
6.0L/M/3.0L/M |
12V/24V |
0.85Bar/1.6Bar |
-70Kpa/-90Kpa |
340g |
125*55*30mm |
| DA45EEDCB |
4.5L/M |
12V 24V |
1.3BAR |
-70KPA |
240G |
93*50*30MM |
| DA45RHAC |
2.6L/M |
220V |
1.8BAR |
-65KPA |
0.68KG |
*** |
| DA45RHDC |
2.6L/M |
12V 24V |
1.8BAR |
-65KPA |
0.22kg |
78.5*31*55.2MM |
| DA45RHDCB |
2.6L/M |
12V 24V |
1.8BAR |
-65KPA |
0.4KG |
73.3*69.5*54MM |
| DA46EEAC |
6L/M |
110V 220V |
1.3BAR |
-70KPA |
1.27KG |
120*79*89MM |
| DA46EEDC |
9L/M |
6V 12V 24V |
1.3BAR |
-70KPA |
220G |
104*31*68MM |
| DA46EEDC-TH |
4.5L/M |
12V 24V |
2.0Bar |
-99KPA |
360G |
143*68*31MM |
| DA46EEDCB |
9L/M |
12V 24V |
1.3BAR |
-70KPA |
245G |
107*68*30MM |
| DA46EEDCB-TH |
4.5L/M |
12V 24V |
2.0Bar |
-99KPA |
450G |
98*68*36MM |
| DA46EESAC |
3L/M |
110V 220V |
2.0Bar |
-90KPA |
1.27KG |
120*79*89MM |
| DA46EESDC |
4.5L/M |
6V 12V 24V |
2.0Bar |
-90KPA |
220G |
104*68*31MM |
| DA46EESDCB |
4.5L/M |
12V 24V |
2.0Bar |
-90KPA |
240G |
107*68*30MM |
| DA48DC |
6.2L/M |
12V 24V |
1.5BAR |
-80KPA |
0.35KG |
86.2*38*56.5MM |
| DA48DCB |
6.2L/M |
12V 24V |
1.5BAR |
-80KPA |
0.35KG |
77.9*30*70MM |
| DA48THDC |
10L/M |
12V 24V |
1.5BAR |
-80KPA |
0.45KG |
92.4*38*78MM |
| DA48THDCB |
10L/M |
12V 24V |
1.5BAR |
-80KPA |
0.6KG |
85.7*58*78MM |
| DA48THSDC |
5.2L/M |
12V 24V |
0.5BAR |
-95KPA |
0.45KG |
92.4*38*78MM |
| DA48THSDCB |
5.2L/M |
12V 24V |
0.5BAR |
-95KPA |
0.6KG |
85.7*58*78MM |
| DA50EEAC |
4.3L/M |
220V 110V |
1.4Bar |
-70KPA |
0.8KG |
123*89*50mm |
| DA50EEDC |
4.3L/M |
6V 12V 24V |
1.4Bar |
-70KPA |
190G |
80*30*54MM |
| DA50EEDCB |
4.3L/M |
12V 24V |
1.4Bar |
-70KPA |
210G |
85*30*54MM |
| DA55DC |
7L/M |
6V 12V |
0.5BAR |
-50KPA |
96G |
57.9*54.3*57.8mm |
| DA60EEAC |
8.0L/M |
220V 110V |
1.4Bar |
-70KPA |
0.7KG |
112*50*89mm |
| DA60EEDC |
8.0L/M |
6V 12V 24V |
1.4Bar |
-70KPA |
220G |
135*31*76MM |
| DA60EEDC-TH |
15L/M 6L/M |
12V 24V |
0.6BAR |
-70kpa -99kpa |
350G |
141*31*76MM |
| DA60EEDCB |
8.0L/M |
12V 24V |
1.4Bar |
-70KPA |
280G |
135*30*76MM |
| DA60EESDC |
6L/M |
6V 12V 24V |
0.6BAR |
-90KPA |
190G |
89*30*43MM |
| DA65EEDC |
8.0L/M |
6V/12V/24V |
0.8Bar |
-60Kpa |
230g |
76*30*68mm |
| DA65EEDCB |
8.0L/M |
6V |
1.4Bar |
-70Kpa |
172g |
76*30*68mm |
| DA67DCB |
13L/M |
12V 24V |
1.5BAR |
-65KPA |
200G |
84.1*63.6*42.4mm |
| DA68DC |
12L/M |
12V 24V |
0.8BAR |
-70KPA |
** |
97.4*44.2*74.8MM |
| DA68DCB |
12L/M |
12V 24V |
0.8BAR |
-70KPA |
** |
84.4*42.6*74.8mm |
| DA68THDCB |
23L/M |
12V 24V |
0.6BAR |
-70KPA |
** |
133*30*75MM |
| DA70AC |
7L/M |
220V 110V |
2.4Bar |
-80KPA |
1.2KG |
139*70*95MM |
| DA70AC-TH |
12L/M 7L/M |
220V |
2.4Bar 4.0Bar |
-80KPA -90KPA |
1.8KG |
190*74*95MM |
| DA70DC |
7L/M |
12V 24V |
2.4Bar |
-80KPA |
0.6KG |
117*43*74MM |
| DA70DC-TH |
12L/M 7L/M |
12V 24V |
2.4Bar 4.0Bar |
-80KPA -90KPA |
0.85KG |
147*43*74MM |
| DA70DCB |
7L/M |
12V 24V |
2.4Bar |
-80KPA |
0.6KG |
117*43*74MM |
| DA70RH |
5.5L/M |
12V 24V |
2.0BAR |
-70KPA |
1.8KG |
122.5*130.7*70mm |
| DA70RHDC |
6.5L/M |
12V/24V |
2.5Bar |
-60Kpa |
1.4Kg |
108*58*124 |
| DA71ACRH |
5.5L/M |
220V |
2BAR |
-65KPA |
1.9KG |
127*70*126.24mm |
| DA72AC2P |
11.5L/M |
110V 220V |
1.2BAR |
-60KPA |
1.4KG |
149.85*70*124.3MM |
| DA72AC4P |
5.5L/M |
110V 220V |
1.2BAR |
-60KPA |
1.4KG |
149.85*70*124.3MM |
| DA72DC |
7L/M |
12V 24V |
1.2BAR |
-60KPA |
1.4KG |
143*74*114.3mm |
| DA72DC-TH |
7L/M |
12V 24V |
1.2BAR |
-60KPA |
1.4KG |
195*74*114.3MM |
| DA75AC |
6L/M |
220V 110V |
0.4Bar |
-93KPA |
1.325KG |
148*70*110mm |
| DA75AC-TH |
6L/M |
220V 110V |
0.4Bar |
-99KPA |
2100G |
217*77*109MM |
| DA75DC |
12L/M |
12V 24V |
0.5Bar |
-80KPA |
0.6kg |
115.2*102.8*50mm |
| DA75DC-TH |
6L/M |
12V 24V |
0.4Bar |
-99KPA |
1100G |
223*43*103MM |
| DA75DCB |
12L/M |
12V 24V |
0.5Bar |
-80KPA |
0.6KG |
92.4*102.5*58.4mm |
| DA75SDC |
6L/M |
12V 24V |
0.5BAR |
-96KPA |
0.6KG |
115.2*102.8*50MM |
| DA75SDCB |
6L/M |
12V 24V |
0.5BAR |
-96KPA |
0.6KG |
92.4*102.5*58.4MM |
| DA80AC |
12L/M |
220V 110V |
3.3Bar |
-75KPA |
2000G |
154*70*104MM |
| DA80AC-TH(P) |
24L/M |
220V 110V |
3.3Bar |
-75KPA |
2525G |
217*71*104mm |
| DA80AC-TH(S) |
12L/M |
220V 110V |
4.0BAR |
-92KPA |
2525G |
217*71*104mm |
| DA80AM大流量 |
9L/M |
12V 24V |
1.0BAR |
-70KPA |
1.8KG |
125.6*104.6*66mm |
| DA80AM小流量 |
9L/M |
12V 24V |
1.5BAR |
-75KPA |
0.9KG |
125.6*104.6*66mm |
| DA80DC |
12L/M |
12V 24V |
3.3Bar |
-75KPA |
860G |
147*52*104mm |
| DA80DC-TH(P) |
24L/M |
12V 24V |
3.3Bar |
-75KPA |
1575G |
200*56*104MM |
| DA80DC-TH(S) |
12L/M |
12V 24V |
4.0BAR |
-92KPA |
1575G |
200*56*104MM |
| DA80DCB |
12L/M |
12V 24V |
3.3Bar |
-75KPA |
930G |
147*52*104mm |
| DA80EX |
4L/M |
220V |
2.0BAR |
-70KPA |
17.6KG |
340.6*184.3*202mm |
| DA80RH |
13L/min |
AC220V |
1.5Bar |
-65kpa |
2.8kg |
122.5*70*130.5 |
| DA80RHDC |
19L/M |
12V/24V |
1.8Bar |
-70kpa |
2Kg |
146*58*139.6mm |
| DA90AC |
16L/M |
220V 110V |
1.2Bar |
-78KPA |
2000G |
156*72*135MM |
| DA90AC-TH(P) |
24L/M |
220V 110V |
1.2Bar |
-78KPA |
2500G |
217*72*134MM |
| DA90AC-TH(S) |
16L/M |
220V 110V |
0.4Bar |
-92KPA |
2500G |
217*72*134MM |
| DA90DC |
16L/M |
12V 24V |
1.2Bar |
-78KPA |
1000G |
157*72*126mm |
| DA90DC-TH(P) |
24L/M |
12V 24V |
1.2Bar |
-92KPA |
1900G |
219*72*129MM |
| DA90DC-TH(S) |
16L/M |
12V 24V |
0.4Bar |
-92KPA |
1900G |
219*72*129MM |
| DA90DCB |
16L/M |
12V 24V |
1.2Bar |
-78KPA |
924G |
157*72*126mm |
| DA90EX |
12.5L/min |
AC220V |
1.1Bar |
-70Kpa |
17.8kg |
349.6*202*195.6mm |
| DA91DCB |
16L/M |
12V 24V |
1.2BAR |
-78Kpa |
1kg |
116.8*72.8*107.3mm |
| DL351DC喷墨陶瓷行业气泵 |
4.5L/M |
12V/24V |
1.1Bar |
-58KPa |
400g |
104*44*68mm |
| Wob-L Piston Pumps for Air |
| Model |
FREE FLOW |
VOLTAGE |
MAX.PRESSURE |
MAX.VACUUM |
WEIGHT |
DIMENSION |
| WA50EEAC |
3L/M |
220V 110V |
2.0Bar |
-65KPA |
0.8KG |
122*61*87.5MM |
| WA50EEDC |
3L/M |
6V 12V 24V |
1.8Bar |
-65KPA |
190G |
73.5*30*53mm |
| WA50EEDC-TH |
6L/M/3L/M |
12V/24V |
2.0Bar |
-65Kpa/-90Kpa |
345g |
122*30*53mm |
| WA50EEDCB |
3.0L/M |
12V/24V |
2.0Bar |
-65Kpa |
240g |
85*53*30mm |
| WA51EEDC |
3L/M |
6V 12V 24V |
2.4Bar |
-65KPA |
190G |
80*30*53mm |
| WA55EEAC |
3L/M |
220V 110V |
2.0Bar |
-65KPA |
0.8KG |
122*61*87.5MM |
| WA55EEDC |
3L/M |
6V 12V 24V |
2.0Bar |
-65KPA |
190G |
80*30*53mm |
| WA55EEDC-TH |
6L/M 3L/M |
12V 24V |
2.0Bar |
-65KPA -90KPA |
290G |
122*30*53mm |
| WA55EEDCB |
3L/M |
12V 24V |
2.0Bar |
-65KPA |
190G |
85*30*53mm |
| WA56DCB |
5.5L/M |
12V 24V |
3.0BAR |
-65KPA |
260G |
69.4*63.7*40MM |
| WA58AC |
14L/M |
110V 220V |
2.8BAR |
-70KPA |
1.35KG |
154.7*70.5*108.6MM |
| WA58DC |
12L/M |
12V 24V |
2.8BAR |
-70KPA |
0.6KG |
118.6*57*89MM |
| WA58DCB |
12L/M |
12V 24V |
2.8BAR |
-70KPA |
0.45KG |
85.5*57*89MM |
| WA60AC |
4.0L/M |
220V 110V |
5.0Bar |
-65KPA |
0.8KG |
117*48*85MM |
| WA60DC |
4.0L/M |
12V 24V |
5.0Bar |
-65KPA |
0.5KG |
118*48*63MM |
| WA60DC-TH |
2*4.0L/M |
12V/24V |
5.0Bar |
-65Kpa |
580g |
156*48*65mm |
| WA60DCB |
4.0L/M |
12V 24V |
5.0Bar |
-65KPA |
0.5kg |
118*48*63MM |
| WA61DC |
6.0L/M |
12V/24V |
5.0Bar |
-75Kpa |
0.72kg |
132*85*44mm |
| WA64DCB |
19L/M |
12V 24V |
2.4BAR |
- |
0.4KG |
88.61*73.57*31MM |
| WA68AC |
13.5L/M |
AC110V 220V |
2.4Bar |
-70KPA |
1.35Kg |
150.4*70.5*108.3mm |
| WA68DC |
13.5L/M |
DC12V 24V |
2.4Bar |
-70kpa |
0.9Kg |
144*60*97mm |
| WA68DCB |
13.5L/M |
12V 24V |
2.4BAR |
-70KPA |
0.65KG |
115.9*60*97.3MM |
| WA70AC |
16L/M |
220V 110V |
3.0Bar |
-77KPA |
1.5KG |
158*63*99mm |
| WA70AC-TH |
32L/M 16L/M |
220V |
3.0Bar 4.0Bar |
-77KPA -90KPA |
1.8KG |
217*52*74mm |
| WA70AC-TH |
32L/M/16L/M |
220V |
3.0Bar/4.0Bar |
-77Kpa/-90Kpa |
1.8Kg |
217*39*74mm |
| WA70DC |
16L/M |
12V 24V |
3.0Bar |
-77KPA |
1.2KG |
147*52*99mm |
| WA70DC-TH |
32L/M 16L/M |
12V 24V |
3.0Bar 4.0Bar |
-77KPA -90KPA |
0.95KG |
200*52*99mm |
| WA70DC-TH |
32L/M/16L/M |
12V/24V |
3.0Bar/4.0Bar |
-77Kpa/-90Kpa |
0.95Kg |
200*99*39mm |
| WA70DCB |
16L/M |
12V 24V |
3.0Bar |
-77KPA |
1.2KG |
147*52*99mm |
| WA72DC |
25L/M |
12V 24V |
2.8BAR |
-75KPA |
0.95KG |
159.5*52*107MM |
| WA72DCB |
25L/M |
12V 24V |
2.8BAR |
-75KPA |
0.65KG |
132*52*107MM |
| WA75DC |
15L/M |
12V 24V |
6BAR |
-60KPA |
0.8KG |
133*108*74MM |
| WA75DC-TH |
23L/M |
12V 24V |
6BAR |
-60KPA |
1.2KG |
189*108*74MM |
| WA75P2AC |
18L/M |
220V 110V |
6BAR |
-70KPA |
2.2KG |
159.15*121.77*87MM |
| WA78DC |
45L/M |
12V 24V |
2.8BAR |
-80KPA |
1.2KG |
130.8*114.5*64MM |
| WA78DCB |
45L/M |
12V 24V |
2.8BAR |
-80KPA |
1.2KG |
130.8*114.5*64MM |
| WA80AC |
12L/M |
AC220V 110V |
7.0BAR |
-80KPA |
1.2KG |
137*102*72MM |
| WA80AC大功率 |
12L/M |
AC220V /AC110V |
7.0Bar |
-85KPA |
3.2KG |
200*129*112mm |
| WA80DC |
12L/M |
12V 24V |
7bar |
-80KPA |
420G |
131*103*52MM |
| WA80DC-THP |
17L/M |
24V |
7.0Bar |
-80Kpa |
1.6Kg |
192*100*63MM |
| WA80DC-THS |
15L/M |
24V |
16BAR |
-90KPA |
1.6KG |
190*100*63MM |
| WAP140V |
119L/M 142L/M |
220V 110V |
- |
700mmhg |
8.4kg |
240*158.9*134mm |
| WPA120H |
80L/M 90L/M |
220V 110V |
- |
740mmhg |
8.4kg |
240*161*197.7mm |
| WPA120P |
86L/M 100L/M |
220V 110V |
- |
-92KPA |
8.4KG |
240*161.1*197.7MM |
| WPA120V |
106L/M 120L/M |
220V 110V |
- |
-700mmhg |
8.4kg |
240*161.1*197.7mm |
| WPA140H |
92L/M 105L/M |
220V 110V |
- |
740mmhg |
8.4kg |
240*158.9*134mm |
| WPA200H |
100L/M |
220V 110V |
- |
740mmhg |
115kg |
275*239.8*165.9mm |
| WPA200P |
165L/M 170L/M |
220V 110V |
7BAR |
-90KPA |
11.5KG |
275*165.9*239.8MM |
| WPA200V |
165L/M 198L/M |
220V 110V |
- |
700mmhg |
11.5kg |
275*165.9*239.8mm |
| WPA40P |
43L/M 56L/M |
220V 110V |
7BAR |
- |
6.8KG |
180*196.7*158.9MM |
| WPA40V |
47L/M 55L/M |
220V 110V |
- |
- |
6.8KG |
180*158.9*196.7MM |
| WPA90H |
58L/M 66L/M |
220V 110V |
-- |
740mmHg |
8.35kg |
240*197.7*161.1mm |
| WPA90P |
58L/M 66L/M |
220V 110V |
- |
- |
8.35KG |
240*197.7*111.1MM |
| WPA90V |
80L/M 90L/M |
220V 110V |
- |
700mmhg |
8.35kg |
240*134*161.1mm |
| WPA90VP |
50L/M |
220V 110V |
7BAR |
-90KPA |
7KG |
240*161.1*197.7MM |
| Rotary pump for air |
| Model |
FREE FLOW |
VOLTAGE |
MAX.PRESSURE |
MAX.VACUUM |
WEIGHT |
DIMENSION |
| RA6/01P-LC |
2.0L/M |
6V |
6KPA |
-6KPA |
30G |
92*29*40mm |
| RA6B/2DC |
4.3L/M |
6V / 12V |
9kpa |
-9kpa |
80g |
61.5*29*29 |
|
|
| |
|
|
|
| |
All rights reserved Wuhan YLK Technology Co.,Ltd |
|
|
| |
TEL：027-82201051 027-82201045 FAX：027-82791020
Mobile：18971649399 18971547056 ADD：Unit D4-3,Huazhong Enterprise city,No.16 Hankoubei Road,Wuhan 430345 China |
|
|
| |
|
|
|
|
